Features


Intelligent Sheet Separating

Avoid loading stuck sheets in a single loading as processing.

High-strength Linear Structure

The loading layout uses the linear structure with stronger rigidity and better loading capacity, which loads a maximum of 20mm thickness for a single sheet.

Flexible Loading Size

The size and type of the loading sheets are flexible and various.

Safety Interlock

The safety interlock prevents operations from irreversible accident in safety.

Applicable Model


p3
c3

P3

All-round sheet fiber laser metal cutting machine

READ MORE >>

C3

Base sheet fiber laser metal cutting machine with full protection

READ MORE >>

Applicable Industry


applicable industry

Engineering Machinery

applicable industry

Automotive Metal Sheet Industry

applicable industry

Electrical Cabinet Industry

Technical Data

Working area: 3048mm*1524mm/1500mm*1200mm/1000mm*1000mm
Module dimensions: 5000mm*2500mm*3100mm
Maximum loading weight: 700kg
Z-axis travel: 450mm
R-axis travel: 0~120°
Z-axis positioning accuracy: ±1mm
R-axis positioning accuracy: ±1°
Operation method: Key operation
Lifting method: Sprocket, chain
